As with other cameras optimum recording can be achieved by keeping the camera lens clean. The unit needs to be installed in the car so that the lens is facing out of the front windscreen (please note that the use of a tinted part of the windscreen will cause loss of image quality.
The Dolphin Road Vision RV1 camera works well at night as well as in the day. It is also worth noting that the SD card should not be removed from the unit within 10 seconds of product power down as in this time the unit will be recording data to the SD card still.
Operation
Upon power up the product starts booting and the LEDs come on, at this point recording has started.
When the product senses impact, the recording continues for an additional
10 seconds. This additional 10 seconds of recording is saved separately as an
event file
The most recently recorded items will be retained in the memory overwriting older files as the memory card becomes full.
Specifications
- Camera Sensor - 1/4" CMOS Image Sensor (US Aptina - Micron)
- Pixel - 1.5 Mega
- Angle Of View - 140 Degrees
- Lens F/N - 1.8
- Video Format - MPEG 4
- Record File Format - AVI + Data File
- Resolution / FPS - 15 FPS / 1280*720, 30 FPS / 640*480
- Record Mode - Anytime Record, Event Record, User Record
- Voice Record - Voice Codec: ACC
- Interface - USB 2.0 / High Speed
- Memory - SD Memory: Max 32GB (SD/SDHC)
- Dimension - 35mm x 35mm x 90mm
- Power Consumption - 5V, 240mA [max]
Special Features
- High Definition Recording
- Smartphone Playback
- 120 Degree Viewing Angle
- Wifi Module
- 3-Axis G-Sensor
- SD Card Included
The Dolphin Road Vision RV1 camera works well at night as well as in the day.
As with other cameras optimum recording can be achieved by keeping the camera lens clean. The unit needs to be installed in the car so that the lens ifacing out of the front windscreen (please note that the use of a tinted part of the windscreen will cause loss of image quality.
It is also worth noting that the SD card should not be removed from the unit within 10 seconds of product power down as in this time the unit will be recording data to the SD card still.
l Product exchange or return will only be accepted on un-opened or defective products
Operation
Upon power up the product starts booting and the LEDs come on, at this point recording has started.
When the product senses impact, the recording continues for an additional
10 seconds. This additional 10 seconds of recording is saved separately as an
event file
The most recently recorded items will be retained in the memory overwriting older files as the memory card becomes full
