Reversing Camera & Dash Monitor Kit

DOLCDM

£100.00 Inc VAT

£83.33 ex. tax
? Tax based on United Kingdom.

Reversing Camera & Dash Monitor Kit - Description

This is a combined reversing camera with a dashboard mounted monitor in one box with all the associated wiring needed. Idea for upgrading cars that maybe have reversing sensors but no rear view camera. The dash mounted monitor avoids the need for expensive interfaces to try and connect to any inbuilt sat nav or dvd screen the car may have and is an alternative to a rear view mirror mounted monitor where it is not suitable to use such a solution or your vehicle does not have a rear view mirror, such as a van.

The camera supplies a colour view of the rear of the vehicle and the camera has self adjusting software to manage low light and night time situations. No more surprises from low level posts in car parks!

Kit Contents

  • Reversing Camera
  • Hole Cutter for Camera
  • 1.8m Power Lead for Camera
  • Dashboard Monitor
  • 1m Power Lead for Monitor
  • 5m Phono/RCA Lead for Connection
  • Instruction Manual

How it works
The reversing camera power lead connects to the cars reversing lights and then powers up and comes on automatically whenever reverse gear is selected. The monitor would connect to a 12v ignition switched supply so it has power whenever the engine is running, the screen remains off until it gets a signal from the camera. Optionally you could also connect the monitor to a 12v ignition switched supply in you wanted it on all the time. The monitor has an on/off switch on the side.

A standard Phono / RCA lead is used to carry the picture from the rear of the vehicle to the monitor, this is 5m long, extension cables are available if required. Alternatively we have a wireless upgrade solution where you can plug a transmitter into the camera and a receiver into the monitor. Useful if you have a commercial van, motorhome or similar vehicle.

Specification

  • 18.8mm Micro Reversing Camera
  • 1/3.7-inch Format CMOS Lens
  • 170 Degree Angle
  • Mirror Imaging
  • 12v DC Power
  • Waterproof IP68
  • Monitor 3.5 inch TFT LCD
  • Resolution 480/234
